Varme Programmable Underfloor Heating Thermostat - Model FH-01

- Floor sensor is included

- Compliments the Varme Cable Mat System sold here.

User Manual

The Varme FH-01 Programmable Underfloor Heating Thermostat has been designed specifically with electric underfloor heating in mind.

The thermostat isenergy efficient, reliable and provides full programming control. It can handle a 16 Amp load, yet is incredibly easy to use with a full 7 day, 24 hour timer.

The FH-01 features 3 different functions

• Floor sensor onlyIdealfor when you only want to control the floor surface temperature. For example, conservatories
• Air & FloorThe thermostat controls the air temperature whilst using the floor sensor to prevent overheating of the floor system
• Remote Air & FloorIdeal for remote control of the air and floor temperature. For example, bathrooms

Probe Installation

It is recommended for the probe to be installed into a conduit so that it can be easily retrieved if required.

Topurchase theVarme underfloor heating system, please click here.

Features

• Floor sensor is included
• Weekdayweekendor 7 day programming options (selectable in software)
• Temperature hold feature
• Day and night temperature feature
• Holiday temperature selection feature
• C F Selectable
• Self learning optimum start on 1st and 3rd level
• Keylock facility
• Frost protection with adjustable temperature setting
• Remote control option (RM1)
• 16A switch rating
• Blue backlight (turns on after 30 seconds)
• Wattage 3,680W
• Voltage 230V AC
• Weight 0.2kg
• DimensionsH 9.8 x W 8.5 x D 1.3 cm
